Transport Dimensions: Width: 12' Length: 42' 2" Height: 13' 6"
Working Dimensions: Width: 12' Length: 42' 2" Height: 13' 6"
Weight: 54, 250lbs
High capacity up to 881 US tph / 800 tph (depending on media sizes & material type)
Maximum feed size 10’’ (250mm). Maximum allowable feed size may vary depending on material type and screenbox media
Quick set-up time
Maintenance platforms on both sides of screen
Extended walkway on the RHS with screen motor stepover for improved health and safety
Heavy duty triple shaft horizontal screenbox with adjustable stroke, angle & speed
Multiple blending chute options to ensure versatility
E-Stops on both sides of the unit
Optional Honda powerunit for hydraulic options such as hydraulic chutes or hydraulic jacking legs
Manual button switchgear panel - NEMA 4 enclosure, NEMA components, breaker, reversing starters for cross conveyors, three position start/ stop push buttons, mains disconnect, emergency stop, 4 x extra starters. Includes panel stand but no lead cord
High spec panel including above in addition to quick release plugs and external interlocking
100ft lead cord - to connect panel to power source
Add hydraulics to roll away chutes - 13hp Honda powerunit
4 no of 6’’ x 16’’ levelling hydraulic jacks & 13hp Honda powerunit
4 no of 6’’ x 24’’ run on hydraulic jacks & 13hp Honda powerunit
2 no of additional crank jacks
Safety tie off cable to keep power clear of the screen
