Screen: 2.44M X 1.2M (8’X4′) Single deck screen; Side tensioined; Screen can be lowered to horizontal
to ease mesh change and maintenance

Conveyor: 500mm (20″) Overside transfer conveyor; 500mm (20″) Wide recirculation conveyor;
Both hydraulically fold for transport; 1200mm (48″) Wide fines conveyor with 2.85m (9’4″) discharge

General: Afterscreen system is quick to detach

Transport Length 48' 6" (14.8m)

Transport Width 9' 10" (3m)

Transport Height 10' 6" (3.2m)

Weight (with Side Conveyor & Twin Pole Magnet): 33,950Kgs (74,847lbs)

Diameter Rotor 33" x 34" (830mm x 860mm)

Output Potential: 250 tph (275 US tph)

  • Output potential 250 tph (275 US tph)
  • Suitable for a variety of feed materials
  • Ideal for recycling & demolition applications
  • Replaceable tine bar cartridge style grizzly feeder
  • Load management system to control feeder speed
  • Proven Terex impact crusher with hydraulic overload protection, 4 bar rotor & twin aprons
  • Crusher speed variation through user friendly PLC control system
  • Fully independent under crusher vibrating pan feeder (Optional)
  • Latest generation power unit that meets EU Stage IV / US Tier 4F emissions legislation
  • HPTO clutch & highly fuel efficient direct drive system
  • Modular conveyor with raise/lower facility to aid clearance of rebar
  • Overband magnet is optional
  • Detachable sizing screen for applications not requiring resizing or recirculation of materials for further processing
