Hopper / Feeder:

  • 2.3m3 (3yd3) Hopper capacity;
  • Two stage ‘Tine’ grizzly feeder as standard;
  • 26mm (1″) Nominal spacing

Impact Crusher:

 860mm (34″) X 610mm (24″) Crusher inlet;

  • 830mm (33″) Wide x 860mm (34″) diameter rotor;
  • 2 High / 2 low configuration as standard;
  • Max OSS – 120mm (4.75″) upper 55mm (2.25″) lower;
  • Min OSS – 40mm (1.4″) upper 20mm (0.75″) lower
  • Hydraulic adjust and hydraulic overload protection as standard

Rotor speed:

 700-930rpm (32-40m/s tip speed)

Output Potential: Up to 250 tph / 275 US tph

Power Unit: Tier 3: CAT C7.1 186kW/250Hp; Tier 4: 202kW/ 275Hp CAT C7.1 engine
Direct drive to crusher via clutch and V belts

Conveyors: 900mm (36″) Wide product conveyor; Product conveyor discharge height: 3420mm (10’8″)

General: Intuitive colour screen control panel

Transport: Track Unit: L 12.05m (39’6″) W 2.5m (8’2″) H 3.2m (10’6″)

Weight (With Side Conveyor & Magnet): Length 13.4m with non-folding conveyor; Length is 12.05m
with optional folding conveyor

  • Output potential 250 tph (275 US tph)
  • Suitable for a variety of feed materials
  • Ideal for recycling & demolition applications
  • Replaceable tine bar cartridge style grizzly feeder
  • Load management system to control feeder speed
  • Proven Terex impact crusher with hydraulic overload protection, 4 bar rotor & twin aprons
  • Crusher speed variation through user friendly PLC control system
  • Fully independent under crusher vibrating pan feeder (Optional)
  • Latest generation power unit that meets EU Stage IV / US Tier 4F emissions legislation
  • HPTO clutch & highly fuel efficient direct drive system
  • Modular conveyor with raise/lower facility to aid clearance of rebar
  • Overband magnet is optional
