CHIEFTAIN 2200 3 DECK

Rent Now

Certified: yes

Weight (Est): 39, 400kg (86,862lbs)

Transport width: 3m (9' 10")

Transport length: 19.77m (64' 11")

Transport height: 3.6m (11' 10")

Working width: 18.3m (60')

Working length: 20.2m (66' 4")

Working height: 7.43m (24' 4")

Weight (Est): 43,400kg (95, 680lbs)

Transport width: 3m (9' 10")

Transport length: 19.77m (64' 11")

Transport height: 3.6m (11' 10")

Working width: 18.3m (60')

Working length: 20.2m (66' 4")

Working height: 7.43m (24' 4")

  • Output Potential: up to 650 tph (715 US tph)
  • 2 x double deck screenboxes
  • Patent pending drive system to switch between 2 and 4 bearing arrangements
  • Radio controlled tipping grid
  • Integrated high capacity variable speed belt feeder
  • Heavy duty single shaft screenboxes with adjustable stroke, angle and speed
  • Hydraulic screen tensioning (bottom deck)
  • Screen walkway and access ladder
  • Hydraulic folding conveyors with excellent stockpiling capacity
  • Double deck vibrating grizzly
  • Radio controlled tracking
  • Anti roll-back
  • Dual Power
  • Auto lubrication system
  • Dust suppression
  • Quick release wedge tensioning (top decks)
